Flame Proof Dynamic Pass Boxes
58885 INR
Product Details:
- Thickness 1.5 mm CRCA sheet (minimum), powder coated or stainless steel as per requirement
- Nozzle Stainless Steel, anti-static (if applicable)
- Power Consumption 50 150 W depending on size and blower
- Lighting Flame Proof LED/Fluorescent Tube Light
- Air Volume 170350 CFM
- Type Flame Proof Dynamic Pass Box
- Air Flow Horizontal/Vertical (as per design)
- Click to View more
X
Flame Proof Dynamic Pass Boxes Price And Quantity
- 58885 INR
- Class 100 / ISO 5 (Inside pass box chamber)
- <65 dB(A) at 1 meter distance
- Flame proof switch socket, UV light timer (optional)
- Toughened / Laminated glass on both doors
- Matt / Glossy finish available
- 1020 mm WC
- EPDM or Neoprene gasket for air tight sealing
- Floor or Wall mounted
Flame Proof Dynamic Pass Boxes Product Specifications
- Approx. 6590 kg
- New
- HEPA H14 & Pre filter G4
- Stainless Steel 304/316 or MS with powder coating
- Pharmaceutical, Chemical, Lab, Research Industries, Hazardous Zones
- HEPA Filter (0.3 micron) and Pre-filter (10 micron)
- Flame proof, Interlocked doors, Audible/Visual alarm, UV germicidal lamp (optional)
- Double Door with Flame Proof Electrical Interlocking
- 220-240V AC, 50 Hz
- Stainless Steel / Mild Steel, Flame Proof finish
- 600 x 600 x 600 mm (Standard); Customized sizes available
- 1.5 mm CRCA sheet (minimum), powder coated or stainless steel as per requirement
- Stainless Steel, anti-static (if applicable)
- 50 150 W depending on size and blower
- 170350 CFM
- Flame Proof LED/Fluorescent Tube Light
- Flame Proof Dynamic Pass Box
- Horizontal/Vertical (as per design)
- Smooth finish, SS 304 or Powder coated MS
- Class 100 / ISO 5 (Inside pass box chamber)
- <65 dB(A) at 1 meter distance
- Flame proof switch socket, UV light timer (optional)
- Toughened / Laminated glass on both doors
- Matt / Glossy finish available
- 1020 mm WC
- EPDM or Neoprene gasket for air tight sealing
- Floor or Wall mounted
Product Description
- " Interlocking System with Electro Magnetic Door Interlock Arrangment System
- Both Side Display with indication & feather Touch Switches For Door Open & Close.
- Light ,UV light , Motor Blower indivisual Swithces with Digital Hour Meter "
- Double Shaft Motor Blower ,1/16 H.P, 2800 R.P.M, 230 volt, 1 Phase
- Electrical Supply 230V AC 1-Phase
- "Fine Filter 5 micron
- Flange Type,Moc:Aluminium,Media:Non Woven synthetic Polyester,Efficiency:95% down 5 Micron,Grade:EU 5 "
- Flourscent light 5-18 watt
- "Hepa Filter 0.3 micron
- Box Type,Moc:Aluminium,Media:Micro Fiber Glass, Efficiency:99.999% down to 0.3 Micron,Grade:H14 "
- Magnehlic Guage 0-25 mm
- "Noise/ Vibration Level Less than 67 dB on scale A when Ambient is not
- greater than 55 dB on Scale A/Minimum"
- Return Air Perforated Grill
- Sandwitch type Door With Clear Glass View pannel (Toughen Glass 5 mm thik)
- SS 304 DOP Port for PAO test
- SS 304 Hinges For Door (3 Hinges per door)
- SS 304 Sheet-1 mm thik sheet matt finished
- SS Automosphere Nozzle (SS 304)
- SS Coving On Boottom for easy cleaning
- UV Light 5-18 watt with hour meter
Other details
- Size : 450 x 450 x 450 mm
- Capacity : Production Capacity 07 Nos per week
- Power : 1 phase
High-Level Contamination Control
Designed for sensitive environments, our Flame Proof Dynamic Pass Box provides Class 100/ISO 5 cleanliness inside the chamber, ensuring optimal protection against contamination. The precision filters-HEPA H14 (0.3 micron) and G4 pre-filter (10 micron)-maintain strict air purity, essential for pharmaceutical and research industries.
Secure and Durable Construction
Crafted from high-grade stainless steel or powder-coated mild steel, the unit ensures durability even in harsh environments. Toughened or laminated view glass on both doors enhances safety, while EPDM or Neoprene gaskets provide airtight sealing. Flame proof electrical interlocking and audible/visual alarms further enhance operator safety.
Adaptable Configurations and Accessories
Choose between matt or glossy finishes, flame proof LED/fluorescent lighting, and optional UV germicidal lamps or UV timers for added sterility. The pass box supports both floor and wall mounting options and can be custom-sized, offering flexibility according to operational and space requirements.
FAQ's of Flame Proof Dynamic Pass Boxes:
Q: How does the flame proof dynamic pass box help maintain cleanliness levels in sensitive environments?
A: The pass box is equipped with high-efficiency HEPA H14 and pre-filters that remove fine particles down to 0.3 microns, ensuring Class 100/ISO 5 air quality inside the transfer chamber. The airtight EPDM or Neoprene gaskets and interlocked doors reduce the risk of cross-contamination between areas.Q: What materials are used in the construction of this pass box, and why are they chosen?
A: Constructed from Stainless Steel 304/316 or powder-coated mild steel, the pass box is designed to withstand demanding environments found in pharmaceutical, chemical, and laboratory settings. These materials offer durability, chemical resistance, and easy cleaning, essential for maintaining strict hygiene standards.Q: When should a flame proof dynamic pass box be used?
A: It should be deployed whenever there is a need for safe transfer of materials between cleanrooms or from non-controlled to controlled environments, especially in industries with explosive or hazardous atmospheres, such as pharmaceuticals, chemicals, and laboratory research facilities.Q: Where can this pass box be installed, and what are the mounting options?
A: This pass box can be floor- or wall-mounted, depending on space and workflow requirements. It is designed for use in pharmaceutical, laboratory, research, and hazardous zone cleanroom facilities across various industrial sectors in India.Q: What process is involved in transferring materials through the pass box?
A: Materials are placed in the pass box, and both doors are interlocked to prevent simultaneous opening. The internal environment is cleaned using filtered airflow and the flame proof components ensure safe operation. Optional UV germicidal lamps can be activated for enhanced sterilization before items are removed.Q: How does the electrical interlocking system enhance safety?
A: The flame proof electrical interlocking ensures that only one door can be opened at a time, preventing direct airflow between rooms and minimizing the risk of cross-contamination or exposure to hazardous environments. It also reduces accidental opening in potentially explosive atmospheres.Q: What benefits does the flame proof dynamic pass box offer in pharmaceutical and hazardous environments?
A: This pass box ensures high-level safety, stringent contamination control, customizable options, and durable construction. The flame proof features, alarms, and interlocking system safeguard both personnel and products, while the smooth and cleanable surfaces maintain compliance with strict regulatory standards.Tell us about your requirement
